FLEX CS 68 18-EC C 18V CIRCULAR SAW BODY 532636

Flex CS 68 18-EC C 532636

18v Compact cordless circular saw with pendulum hood

Ideal for traditional applications in dry construction and refurbishing, e.g. for making saw cuts through plasterboard, concrete fibre boards, wood materials, such as formwork panels and chipboard or OSB boards
Angle scale from 0 ° to 56 °. With preset angles of 22.5°/ 45°, and 56°. Easy to read, precision adjustment via long clamping lever
High-quality magnesium die-castings for protective cover and base plates
Guide rails for straight, splinter-free and powerful cuts. The guide rail slots are located directly in the base plate. Compatible with FLEX and other systems
Brushless motor with greater efficiency and a longer service life
18 V EC motor with overload protection and temperature monitoring
Electronic management system (EMS) protects the machine, extends the service life, and increases efficiency
Motor brake stops the saw blade in 2 seconds
Integrated LED lamp for optimum illumination of the work area.
Spindle lock: for quick replacement of blades
With metal bracket for flexible attachment
Connector for external dust extraction Ø 27, 36 mm
Woodshaving collection bag for low-dust operation, simple to empty
FLEX battery system: suitable for all FLEX 18 V battery packs.
Does not include battery and charger

FEATURES:

Brushless EC Motor Technology
Overload Protection
Restart Protection
Spindle Lock
Dust Extraction

SPECIFICATIONS:

Battery voltage 18 V
Battery capacity 2.5 / 5.0 / 8.0 Ah
Max. no-load speed 5800 rpm
Cutting depth 0-68 mm
Cutting depth, mitre cut (45°) 0-50 mm
Saw blade diameter 190 mm
Saw blade hole 20 mm
Pivoting range 0.56°
Angle preset 0 / 22,5 / 45°
Dimensions WxLxH 352 x 200 x 273 mm
Weight without battery pack 4.3 kg

COMES WITH:

1 Standard circular saw blade with alternating teeth (532703)
1 Parallel stop
1 Dust bag
